QSFP 10km Gigabit Fiber Transceiver 1310nm QSFP28-100G-LR4

Product Categories
Shenzhen Gaveid communication Technology Co.,Ltd
Contact Now

QSFP 10km Gigabit Fiber Transceiver 1310nm QSFP28-100G-LR4

Brand Name : Gvdlink

Model Number : GVD-QSFP-100G-LR4-S

Certification : CE,ROHS,FCC

Place of Origin : China

MOQ : 1pcs

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram, L/C,Paypal

Supply Ability : 3500pcs per week

Delivery Time : 1-5 working days

Packaging Details : Standard neutral or brand packing

Product name : optical transceiver

Type : QSFP28

Data Rate : 100Gb/s

Wavelength : 1310nm

Distance : 10km

Connector : LC

Transmitter Type : 4 x LAN WDM DFB

Operating temprature : -20~70 C -40~85 C

Warranty : 3 years

Contact Now

02311KNU QSFP28-100G-LR4 Compatible QSFP 100GBASE-LR4 10km transceiver



Description



item Description
Part number 02311KNU QSFP28-100G-LR4
Version support Supported in V200R001C00 and later versions
Transceiver form factor QSFP28
Transmission speed 100GE
Center wavelength (nm) 1295, 1300, 1304, 1309
Standards compliance 100GBASE-LR4
Connector type LC
Type of the end face of the fiber ceramic ferrule PC or UPC
Applicable cable and maximum transmission distance Single-mode fiber (G.652) (with diameter of 9 μm): 10 km
Modal bandwidth    -
Transmit power (dBm) -4.3 to +4.5
Maximum receiver sensitivity (dBm) -8.6
Overload power (dBm) 4.5
Extinction ratio (dB) ≥ 2
Operating temperature 0°C to 70°C



  • 100%tested
  • Fully product line
  • High Quality with ISO9001 , TUV , CE , FCC , UL and RoHS certificates

  • 3 year Warranty

Applications

  • OTN OTU4 Metro Area Networks

  • 100GBASE-LR4 Ethernet Data Center Networks

Huawei QSFP28 100G Product series

Part number Model Description
02311KNU QSFP28-100G-LR4 100GBASE LR4 QSFP LC 10km
02311MNM QSFP28-100G-PSM4 100GBASE-PSM4 QSFP 500m
02311GBW QSFP28-100G-SR4 100GBASE-SR4 850nm 100m
02313EEK QSFP28-100G-BIDI 100G PAM4 BiDi 850/910nm 100m
02311MNP QSFP-100G-CLR4 100GBASE-CLR4 1271/1291/1311/ 1331nm 2km
02311MNN QSFP-100G-CWDM4 100GBASE-CWDM4 1271/1291/1311/ 1331nm 2km
02312UJN QSFP-100G-CWDM4-500 100GBASE-CWDM4 1271/1291/1311/ 1331nm 500m
02311UPS QSFP-100G-LR4-Lite 100GBASE-LR4 1295/1300/1304/1309nm 2km
02312DAT QSFP-100G-eCWDM4 100GBASE-eCWDM4 1271/1291/1311/1331 10km
02311YXR QSFP-100G-ER4-Lite 100GBASE-ER4 1295/1300/1304/1309nm 40km
02311QUK QSFP-100G-SWDM4 100G-SWDM4 850nm 100m



Guarantee
We provide 3 years warranty for all the optical transceivers from the date of shipment .

Our products are compatible with Cisco , Ciena , H3C , Extreme , HP , Foundry , Avaya , D-link , Alcatel , Riverstone , Enterasys , Netgear , Nortel , Juniper , Ruijie , Zyxel , Huawei , etc .



Our product line show



QSFP 10km Gigabit Fiber Transceiver 1310nm QSFP28-100G-LR4
